Step-Down DC/DC Converters Integrated Switch 9V to 30V Input Max., Texas Instruments### 直流/直流开关调节器转换器(集成开关),Texas InstrumentsTexas Instruments 的此系列高度集成的高效开关稳压器包括步升(升压)、步降(降压)、步升/降(增压/降压)和反相类型,为每个直流稳压器应用提供高效的解决方案。
Step-Down DC/DC Converters Integrated Switch 9V to 30V Input Max., Texas Instruments
### 直流/直流开关调节器转换器(集成开关),Texas Instruments
Texas Instruments 的此系列高度集成的高效开关稳压器包括步升(升压)、步降(降压)、步升/降(增压/降压)和反相类型,为每个直流稳压器应用提供高效的解决方案。
得捷:
IC REG BUCK ADJ 2A DL 14HTSSOP
立创商城:
TPS54283PWP
德州仪器TI:
4.5V to 28V Input, Dual 2A Output, 300kHz Step-Down Converter with Internal Compensation
欧时:
### Step-Down DC/DC Converters Integrated Switch 9V to 30V Input Max., Texas Instruments### 直流/直流开关调节器转换器(集成开关),Texas InstrumentsTexas Instruments 的此系列高度集成的高效开关稳压器包括步升(升压)、步降(降压)、步升/降(增压/降压)和反相类型,为每个直流稳压器应用提供高效的解决方案。
贸泽:
开关稳压器 2A Non-Synch Buck Converter
艾睿:
Adjust the voltage level of your devices with this step down TPS54283PWP DC to DC converter from Texas Instruments. This converter&s;s 2 outputs can produce a current up to 2 A. It only needs a voltage of at least 4.5 V while not exceeding 28 V to effectively power your circuit. With an adjustable output that has a voltage of 0.8 to 25.2 V, this is power management at its best. This converter is 85typ % efficient. It has a switching frequency of 375 kHz. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This converter has an operating temperature range of -40 °C to 85 °C.
安富利:
Conv DC-DC Dual Step Down 4.5V to 28V 14-Pin HTSSOP EP Tube
Chip1Stop:
Step-Down Regulator Dual 2A Non-Synchronous Step Down SWIFT? Converter with Integrated High Side MOSFET, 300 kHz Conv DC-DC 4.5V to 28V Step Down Dual-Out 0.8V to 25.2V 2A 14-Pin HTSSOP EP Tube
Verical:
Conv DC-DC 4.5V to 28V Synchronous Step Down Dual-Out 0.8V to 25.2V 2A/2A 14-Pin HTSSOP EP Tube
Newark:
# TEXAS INSTRUMENTS TPS54283PWP DC/DC Switching Regulator, Buck, 2 Output, 4.5 V to 28 V in, 25.2 V/2 A out, 370 kHz, HTSSOP-14
Win Source:
IC REG BUCK ADJ 2A DL 14HTSSOP
DeviceMart:
IC REG BUCK ADJ 2A DL 14HTSSOP
输出接口数 2
输出电压 0.8V ~ 25.2V
输出电流 2 A
静态电流 1.80 mA
调节输出数 2
输出功率 1.60 W
开关频率 310 kHz
过温保护 Yes
拓扑结构 Buck
输入电压Max 28 V
输入电压Min 4.5 V
输出电压Max 25.2 V
输出电压Min 0.8 V
输出电流Max 2 A
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 4.5 V
输入电压 4.5V ~ 28V
安装方式 Surface Mount
引脚数 14
封装 HTSSOP-14
长度 5 mm
宽度 4.4 mm
高度 1.15 mm
封装 HTSSOP-14
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS54283PWP TI 德州仪器 | 当前型号 | 当前型号 |
TPS54283PWPR 德州仪器 | 类似代替 | TPS54283PWP和TPS54283PWPR的区别 |
TPS54283PWPG4 德州仪器 | 类似代替 | TPS54283PWP和TPS54283PWPG4的区别 |
TPS54283PWPRG4 德州仪器 | 类似代替 | TPS54283PWP和TPS54283PWPRG4的区别 |
