DDR存储器终端的6A输出同步降压转换器
series 转换器,DDR 稳压器 IC 1 输出 20-VQFN(3.5x4)
立创商城:
TPS53317RGBT
德州仪器TI:
Low Input Voltage, 6A Synchronous Step-Down SWIFT™ Converter for DDR Memory Termination
得捷:
IC REG CONV DDR 1OUT 20VQFN
艾睿:
Adjust the voltage level of your devices with this step down TPS53317RGBT DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 6 A. Using the part will provide the power your application needs by requiring a voltage only of 1 V and not exceeding a voltage of 6 V. With an adjustable output that has a voltage of 0.6 to 4.2 V, this is power management at its best. It has a switching frequency of 600|1000 kHz. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This converter has a minimum operating temperature of -40 °C and a maximum of 85 °C.
安富利:
DDR/DDR2/DDR3/DDR3L/DDR4 Termination Regulator 6A 4.5V to 6.5V 20-Pin VQFN T/R
Chip1Stop:
Conv DC-DC Single Step Down 1V to 6V 20-Pin VQFN EP T/R
Verical:
Conv DC-DC 4.5V to 6.5V Synchronous Step Down Single-Out 0.6V to 2V 6A 20-Pin VQFN EP T/R
力源芯城:
用于DDR存储器终端的6A输出同步降压转换器
DeviceMart:
IC REG BUCK SYNC ADJ 6A 20VQFN
Win Source:
D-CAP+ Converter, DDR Voltage Regulator IC 1 Output 20-VQFN 3.5x4.0
输出接口数 1
输出电压 0.6V ~ 2V
输出电流 6 A
静态电流 320 µA
调节输出数 1
开关频率 600kHz, 1MHz
拓扑结构 Buck
输入电压Max 6 V
输入电压Min 1 V
输出电流Max 6 A
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压Min 1 V
输入电压 1V ~ 6V
安装方式 Surface Mount
引脚数 20
封装 VQFN-20
封装 VQFN-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 转换器,DDR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS53317RGBT TI 德州仪器 | 当前型号 | 当前型号 |
TPS53317RGBR 德州仪器 | 类似代替 | TPS53317RGBT和TPS53317RGBR的区别 |
