TS-106-G-A

SAMTEC  TS-106-G-A  板至板连接, TS系列, 6 触点, 针座, 2.54 mm, 通孔安装, 1 排

Precision Screw Machined 2.54mm Header Terminal Strips - TS Series

TS series board to board through hole single row precision screw machined terminal header strips with a 2.54mm pitch and a 3.96mm tail length. The body of these TS series board-to-board PCB precision machined header terminal strips is made from black glass filled polyester and the contacts are made from phosphor bronze with a 0.51μm gold plating. The temperature range at which these TS series machined terminal strips can be used is -55 to +125°C.

### 注

These TS series PCB board-to-board screw machined header strips mate with the following:

SS series socket strips - see stock number 767-9707 typically.

SL series socket strips - see stock number 767-9319 typically.

### 2.54 mm 板对板和线对板 -
