TSW-109-08-F-D-LL

SAMTEC TSW-109-08-F-D-LL Board-To-Board Connector, 2.54mm, 18Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 18 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 18POS 2.54MM

艾睿:
This unshrouded TSW-109-08-F-D-LL header connector from Samtec is used for jumper posts to support physical configuration options on printed circuit boards. This HDR connector&s;s 18 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a header type gender. This is a 2-row connector. It has a straight body orientation. It has a maximum voltage rating of 550 VAC. This device has a maximum current rating of 6.3 A/contact. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. This product is 22.86 mm long, 8.38 mm tall and 5.08 mm deep. TSW-109-08-F-D-LL is housed in black polyester.

Verical:
Conn Unshrouded Header HDR 18 POS 2.54mm Solder ST Top Entry Thru-Hole Bulk

Newark:
# SAMTEC  TSW-109-08-F-D-LL  Board-To-Board Connector, 2.54 mm, 18 Contacts, Header, TSW Series, Through Hole, 2 Rows
