TSW-108-08-G-T-RA

SAMTEC TSW-108-08-G-T-RA Board-To-Board Connector, 2.54mm, 24Contacts, Header, TSW Series, Through Hole, 3Rows

针座 通孔，直角 24 位置 0.100"（2.54mm）

欧时:
Classic PCB HDR Strips 0.100"

得捷:
CONN HEADER R/A 24POS 2.54MM

艾睿:
Mounting this unshrouded TSW-108-08-G-T-RA header connector from Samtec to your printed circuit board can help you support multiple physical configuration options. This HDR connector&s;s 24 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 3-row connector. It has a right angle body orientation. It has a header type gender. Its pitch is 2.54 mm. It has a maximum voltage rating of 450 VAC. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. TSW-108-08-G-T-RA is housed in black polyester. This product is 20.32 mm long, 8.12 mm tall and 14.98 mm deep. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 24 POS 2.54mm Solder RA Thru-Hole

Newark:
# SAMTEC  TSW-108-08-G-T-RA  Board-To-Board Connector, 2.54 mm, 24 Contacts, Header, TSW Series, Through Hole, 3 Rows
