TSW-107-07-S-S

Conn Unshrouded Header HDR 7POS 2.54mm Solder ST Thru-Hole

Connector Header Through Hole 7 position 0.100" 2.54mm

欧时:
through-hole hdr strips for 0.100 pit

得捷:
CONN HEADER VERT 7POS 2.54MM

艾睿:
This unshrouded TSW-107-07-S-S header connector from Samtec is used for jumper posts to support physical configuration options on printed circuit boards. This HDR connector&s;s 7 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. It has a header type gender. This is a 1-row connector. It has a maximum voltage rating of 550 VAC. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. TSW-107-07-S-S is housed in black polyester. This product is 17.78 mm long, 8.38 mm tall and 2.54 mm deep.

安富利:
Conn Unshrouded Header HDR 7 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-107-07-S-S  .025 Sq. Terminal Strips
