施密特反相器;•高输出电流：±24 mA（分钟）在VCC =3 V•超高速运转：TPD =3.7 ns（典型值）在VCC = 5 V，50 pF的•工作电压范围：VCC（OPR）= 1.65至5.5 V•5.5-V宽容输入•5.5-V断电保护输出•匹..
逻辑类型Logic Type| 反相施密特触发器 Inverting Schmitt trigger \---|--- 电路数Number of Circuits| 1 输入数Number of Inputs| 1 电源电压VccVoltage - Supply| 1.65v~5.5v 静态电流IqCurrent - Quiescent Max| 1µA 输出高，低电平电流Current - Output High, Low| -50mA,50mA 低逻辑电平Logic Level - Low| 0.12V~0.25v 高逻辑电平Logic Level - High| 0.75v~0.88v 传播延迟时间@Vcc，CLMax Propagation Delay @ V, Max CL| 3.7ns @ 5V，50pF Description & Applications| Schmitt Inverter ；• High output current: ±24 mA min at VCC = 3 V • Super high speed operation: tpd = 3.7 ns typ. at VCC = 5 V, 50 pF • Operation voltage range: VCC opr = 1.65 to 5.5 V • 5.5-V tolerant input • 5.5-V power down protection output • Matches the performance of TC74LCX series when operated at 3.3- V VCC 描述与应用| 施密特反相器;•高输出电流：±24 mA（分钟）在VCC =3 V •超高速运转：TPD =3.7 ns（典型值） 在VCC = 5 V，50 pF的 •工作电压范围：VCC（OPR）= 1.65至5.5 V •5.5-V宽容输入 •5.5-V断电保护输出 •匹配的性能时TC74LCX系列工作在3.3-V VCC
