URZ1H102MHD

1mF ±20% 50V Φ18mm 20mm

铝电解器 径向，Can - 105°C 时为 1000 小时

立创商城:
1000uF ±20% 50V

得捷:
CAP ALUM 1000UF 20% 50V RADIAL

艾睿:
Using the aluminum anode based electrolytic URZ1H102MHD electrolytic capacitor, developed by Nichicon, you can filter out lower signal frequencies. It can withstand a voltage of 50 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. It has a tolerance of 20%. Its leakage current is 1500@1Min|500@2Min μA. Its capacitance value is 1000uF. This part has a lead diameter of 0.8 mm and a pitch of 7.5 mm. This product is 20 mm tall with a diameter of 18 mm. The URZ1H102MHD aluminum electrolytic capacitor has a radial termination style.

安富利:
Cap Aluminum 1000uF 50V 20% 18 X 20mm Radial 7.5mm 830mA 1000 hr 105°C Bulk

Chip1Stop:
Cap Aluminum Lytic 1000uF 50V 20% 18 X 20mm Radial 7.5mm 830mA 1000h 105℃ Bulk

TME:
Capacitor: electrolytic; THT; 1000uF; 50VDC; Ø18x20mm; Pitch:7.5mm

Verical:
Cap Aluminum Lytic 1000uF 50V 20% 18 X 20mm Radial 7.5mm 830mA 1000h 105C Bulk
