V42MLA1206A

SMT 瞬态抑制器 - ML 系列多层半导体陶瓷构造，提供双向钳位电压。 感应开关抑制或其它快速电气瞬态事件，使这些装置有利于实现成品的电磁兼容性。适合于集成电路和晶体管的板载瞬态电压保护 在许多应用场合中可以代替较大的表面安装 TVS 齐纳管 ### 瞬态电压抑制器（ 陶瓷）

SMT 瞬态抑制器 - ML 系列

多层半导体陶瓷构造，提供双向钳位电压。 感应开关抑制或其它快速电气瞬态事件，使这些装置有利于实现成品的电磁兼容性。

适合于集成电路和晶体管的板载瞬态电压保护

在许多应用场合中可以代替较大的表面安装 TVS 齐纳管

得捷:
VARISTOR 53V 180A 1206

立创商城:
V42MLA1206A

欧时:
Littelfuse ML 系列 60V 180A 0.8J 92V钳位电压 陶瓷瞬态电压抑制器 V42MLA1206A, 42V最大直流额定电压

艾睿:
When different voltages are applied to this V42MLA1206A MOV from Littelfuse will change resistance. Its maximum surge current is 180 A. This device&s;s clamping current is 1 A and clamping voltage is 92 V. This voltage dependent resistor has an operating temperature of -55 to 125 °C. This product comes packaged in bulk, so the parts will be stored loosely. Mount your voltage dependent resistor on a printed circuit board using surface mount technology to produce the most effective results. The maximum AC voltage rating is 30 VAC and the maximum DC voltage rating is 42 VDC. This product is 3.2 mm long, 1.8 mm tall and 1.6 mm deep. This varistor has a voltage of 60 V. This device utilizes multilayer technology. Its capacitance value is 425pF.

Allied Electronics:
ML Series 60V 180A 0.8J 92V Clamp 1206 Ceramic Transient Voltage Suppressor

Chip1Stop:
Var MLV 30VAC/42VDC 180A 60V 1206 SMD Automotive Bulk

Verical:
Var MLV 30VAC/42VDC 180A 60V 1206 SMD Bulk
