0836129020

MOLEX  0836129020  连接器, 微型D sub, 直角, Commercial Micro-D系列, 插头, 15 触点, 焊接, 电路板安装

15 位 D 型，微型 D 插头，公引脚

得捷:
CONN MICRO-D PLUG 15POS R/A SLDR

e络盟:
D-Sub 连接器, 直角, Micro D, 插头, Commercial Micro-D系列, 15 触点, 焊接

艾睿:
The commercial micro-d 0836129020 DVI connector from Molex is ideal for communicating with any serial connections you have. This 2-row connector has a single port. It has a right angle body orientation. Its pitch is 1.27 mm. It has a maximum voltage rating of 350 VAC. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This DVI connector has an operating temperature of -40 to 125 °C. This product is 7.82 mm tall. Its 15 terminals use the solder termination method.

安富利:
Conn Commercial Micro-D PIN 15 POS 1.27mm Solder RA Thru-Hole 15 Terminal 1 Port Tube

Chip1Stop:
Conn Commercial Micro-D PIN 15 POS 1.27mm Solder RA Thru-Hole 15 Terminal 1 Port Tube

Verical:
Conn Micro D-Subminiature F 15 POS 0.63mm Solder RA Thru-Hole 15 Terminal 1 Port Commercial Micro-D Tube

Newark:
# MOLEX  0836129020  Micro D Sub Connector, Right Angle, Commercial Micro-D Series, Plug, 15, Solder, PCB Mount
