0010101033

5.08毫米（ 0.200 “ ）间距KK® PC板连接器，顶面入口安装方式C， 1.0微米（ 40μ ”），锡（Sn ） ， 3电路 5.08mm .200" Pitch KK® PC Board Connector, Top Entry Mount Style C, 1.0μm 40μ" Tin Sn, 3 Circuits

3 位置 插座 0.200"（5.08mm） 通孔 锡

得捷:
CONN RCPT TOP VERT 3POS TIN

贸泽:
Molex 5.08mm KK PCB Conn Top/E VrC 3Ckt

艾睿:
As an added safety precaution, the socket strip 0010101033 header connector from Molex will prevent and protect components on your circuit board from accidentally touching each other. This SKT connector&s;s 3 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a straight body orientation. It has a socket type gender. This is a 1-row connector. Its pitch is 5.08 mm. It has a maximum voltage rating of 250 V. This device has a maximum current rating of 7 A/contact. This component comes in tray packaging, useful for fast picking and placing of your parts. 0010101033 is housed in natural nylon. It uses the solder termination method. This product is 15.24 mm long, 11.5 mm tall and 10 mm deep. This connector has an operating temperature of 0 to 75 °C.

Verical:
Conn Socket Strip RCP 3 POS 5.08mm Solder ST Thru-Hole KK® Tray
