低压差稳压器
PMIC - 稳压器 - 线性 正 固定 1 输出 150mA SOT-23-5
得捷:
IC REG LINEAR 1V 150MA SOT23-5
立创商城:
LP2983IM5X-1.0/NOPB
德州仪器TI:
150-mA, 16-V, low-dropout voltage regulator with low output voltage & enable
贸泽:
低压差稳压器
艾睿:
This LDO LP2983IM5X-1.0/NOPB linear regulator developed by Texas Instruments keeps the power stable! It has an overall accuracy of ±3 %. This voltage regulation device&s;s single output can produce a current up to 0.15 A. By only needing an input voltage of 2.2 V with a maximum of 16 V, this is the best way to control the power in your circuit. With a fixed output that has a voltage of 1 V, this is power management at its best. Operate at a constant current by utilizing the line regulation of 0.016%/V. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.
安富利:
LDO Regulator Pos 1V 0.15A 5-Pin SOT-23 T/R
Verical:
LDO Regulator Pos 1V 0.15A 5-Pin SOT-23 T/R
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 1V 150mA SOT-23-5
输出接口数 1
输出电压 1 V
输出电流 150 mA
供电电流 95µA ~ 2mA
静态电流 0.065 mA
输出电容类型 Ceramic
跌落电压 1.20 V
调节输出数 1
输入电压Max 16 V
输入电压Min 2.2 V
输出电压Min 1 V
输出电流Max 0.15 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±3 %
输入电压 16V ~ 2.2V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
封装 SOT-23-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LP2983IM5X-1.0/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LP2983IM5-1.0/NOPB 德州仪器 | 类似代替 | LP2983IM5X-1.0/NOPB和LP2983IM5-1.0/NOPB的区别 |
LP2983IM5-1.0 德州仪器 | 类似代替 | LP2983IM5X-1.0/NOPB和LP2983IM5-1.0的区别 |
LP2983IM5X-1.0 德州仪器 | 类似代替 | LP2983IM5X-1.0/NOPB和LP2983IM5X-1.0的区别 |
