LT1460EIS8-5

V-Ref Precision 5V 40mA 8Pin SOIC N

Description

The  LT®1460  is  a  micropower  bandgap  reference  that combines very high accuracy and low drift with low power dissipation and small package size. This series reference uses curvature compensation to obtain low temperature coefficient and trimmed precision thin-film resistors to achieve high output accuracy. The reference will supply up to 20mA with excellent line regulation characteristics, making it ideal for precision regulator applications.

Features

Trimmed to High Accuracy: 0.075% Max

Low Drift: 10ppm/°C Max

Industrial Temperature Range

Temperature Coefficient Guaranteed to 125°C

Low Supply Current: 130µA Max LT1460-2.5

Minimum Output Current: 20mA

No Output Capacitor Required

Reverse Battery Protection

Minimum Input/Output Differential: 0.9V

Available in S0-8, MSOP-8, PDIP-8, TO-92 and SOT- 23 Package
