200毫安,低IQ ,低噪声,低压差稳压器用于便携式设备 200-mA, Low-IQ, Low-Noise, Low-Dropout Regulator for Portable Devices
PMIC - 稳压器 - 线性 正 固定 1 输出 200mA 4-X2SON(1x1)
立创商城:
TLV70733PDQNR
德州仪器TI:
200-mA, low-IQ, low-dropout voltage regulator with enable & active output discharge
得捷:
IC REG LINEAR 3.3V 200MA 4X2SON
艾睿:
This LDO TLV70733PDQNR linear regulator from Texas Instruments is used to manipulate the voltage level of your circuit. This device has a maximum power dissipation of 400 mW. Its typical dropout voltage at current is 0.045@30mA|0.22@150mA V. It has an overall accuracy of ±0.5Typ %. This voltage regulation device&s;s single output can produce a current up to 0.2 A. It only needs a voltage of at least 2 V while not exceeding 5.5 V to effectively power your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. By operating at a load regulation of 10mVTyp and line regulation of 1mVTyp you can provide a constant voltage at your output. Its maximum power dissipation is 400 mW. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. Its polarity is positive. The maximum dropout voltage is 0.27@150mA V. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 85 °C.
安富利:
LDO Regulator Pos 3.3V 0.2A 4-Pin X2SON T/R
Chip1Stop:
LDO Regulator Pos 3.3V 0.2A 4-Pin X2SON EP T/R
Verical:
LDO Regulator Pos 3.3V 0.2A 4-Pin X2SON EP T/R
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V 200mA 4-X2SON 1x1
输出接口数 1
输出电压 3.3 V
输出电流 200 mA
耗散功率 400 W
静态电流 25.0 µA
输出电容类型 Ceramic
跌落电压 0.22V @150mA
调节输出数 1
输入电压Max 5.5 V
输入电压Min 2 V
输出电压Min 3.3 V
输出电流Max 0.2 A
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 400 mW
输入电压 ≤5.5 V
安装方式 Surface Mount
引脚数 4
封装 4-X2SON
封装 4-X2SON
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TLV70733PDQNR TI 德州仪器 | 当前型号 | 当前型号 |
TLV70733PDQNT 德州仪器 | 类似代替 | TLV70733PDQNR和TLV70733PDQNT的区别 |
TLV70733DQNR1 德州仪器 | 类似代替 | TLV70733PDQNR和TLV70733DQNR1的区别 |
TLV70733DQNR 德州仪器 | 类似代替 | TLV70733PDQNR和TLV70733DQNR的区别 |
