TPS2814D

TEXAS INSTRUMENTS  TPS2814D  驱动器芯片, MOSFET, 驱动器, 高压侧, 4V-14V电源, 2A输出, 24ns延迟, SOIC-8

MOSFET 和 IGBT 驱动器，高达 2.5A，Texas Instruments

Texas Instruments 专用栅极驱动器 IC 系列适用于 MOSFET 和 IGBT 应用。 设备可提供适合与 MOSFET 和 IGBT 电源设备兼容的高电流输出，且提供各种配置和封装类型。

得捷:
IC GATE DRVR LOW-SIDE 8SOIC

立创商城:
低边 MOSFET 灌:2A 拉:2A

德州仪器TI:
2-A/2-A dual-channel gate driver with two AND inputs for each output

欧时:
Texas Instruments TPS2814D 双 MOSFET 功率驱动器, 2A, 4 → 14 V电源, 8引脚 SOIC封装

艾睿:
Driver 2A 2-OUT High Speed Inv 8-Pin SOIC Tube

安富利:
MOSFET DRVR 2A 2-OUT High Speed Inv 8-Pin SOIC Tube

Chip1Stop:
Driver 2A 2-OUT High Speed Inv 8-Pin SOIC Tube

Verical:
Driver 2A 2-OUT High Speed Inv 8-Pin SOIC Tube

Newark:
The TPS2814D is a Dual High Speed MOSFET Driver capable of delivering peak currents of 2A into highly capacitive loads. This performance is achieved with a design that inherently minimizes shoot-through current and consumes an order of magnitude less supply current than competitive products. The TPS2814 has 2-input gates that give the user greater flexibility in controlling the MOSFET. It is a dual 2-input AND driver with one inverting input on each driver. The CMOS input circuit has a positive threshold of approximately 2/3 of VCC, with a negative threshold of 1/3 of VCC and very high input impedance in the range of 109Ω. Noise immunity is also very high because of the Schmidt trigger switching. In addition, the design is such that the normal shoot-through current in CMOS when the input is biased halfway between VCC and ground is limited to less than 6mA. The basic driver portion of the circuits operates over a supply voltage range of 4 to 14V with a maximum bias current of 5µA.

力源芯城:
2输入AND高速MOSFET驱动器,一路同相,一路反
