1704936

Phoenix Contact 7.62mm COMBICON MKDS 5 系列印刷电路板端子块7.62mm 节距 COMBICON MKDS 5 系列垂直通孔安装印刷电路板端子块，具有 6mm2 突起笼形夹螺钉连接。 这些 7.62mm COMBICON MKDS 5 系列印刷电路板端子块提供 2 和 3 位置基座，用于多用途配置。 有关螺丝刀，请参见 390-9641### Phoenix Contact COMBICON 7.62mm 节距印刷电路板端子块

Contact 7.62mm COMBICON MKDS 5 系列印刷电路板端子块

7.62mm 节距 COMBICON MKDS 5 系列垂直通孔安装印刷电路板端子块，具有 6mm2 突起笼形夹螺钉连接。 这些 7.62mm COMBICON MKDS 5 系列印刷电路板端子块提供 2 和 3 位置基座，用于多用途配置。

有关螺丝刀，请参见 390-9641

得捷:
TERM BLK 3P SIDE ENT 7.62MM PCB

欧时:
MKDS 5/3-7,62 3way 7.62mm terminal block

立创商城:
7.62mm 排数:1 每排P数:3

贸泽:
固定接线端子 3P 7.62mm

艾睿:
This 1704936 PCB terminal block developed by Phoenix Contact will mend different gage wires together. It has a straight body orientation. It has a maximum voltage rating of 500 V@IEC|300V@UL. Its pitch is 7.62 mm. This is a 1-row connector. 1704936 is housed in polyamide. This device has a maximum current rating of 32@IEC|10@UL A. This product is 22.86 mm long, 21.5 mm tall and 12.5 mm deep. It uses the solder termination method. Its wire is 10-24@IEC|10-30@UL AWG.

Allied Electronics:
Conn; Term Blk; PCB; Screw; 3; 7.62 mm; Front; 24-10 AWG; Green; 32 A; 500; M 3

Verical:
Conn PC Terminal Block 3 POS 7.62mm Solder ST Thru-Hole 32A Cardboard

MASTER:
PCB terminal block - nominal current: 32 A - rated voltage III/2: 630 V - nominal cross section: 4 mm² - pitch: 7.62 mm - number of positions: 3 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connect

Online Components:
Conn Terminal Block 3 POS 7.62mm Solder ST Thru-Hole 32A

Electro Sonic:
PCB terminal block - nominal current: 32 A - rated voltage III/2: 630 V - nominal cross section: 4 mm² ...
