16SVPA82MAA

PANASONIC ELECTRONIC COMPONENTS  16SVPA82MAA  铝电解电容, SVPA系列, 82 µF, Radial Can - SMD, 0.03 ohm, 16 V, 2000 hours @ 105°C

* Low ESR 18mΩ max. * High ripple 4240mArms * RoHS compliance, Halogen free

得捷:
CAP ALUM POLY 82UF 20% 16V SMD

立创商城:
82uF ±20% 16V

艾睿:
By adding one of Panasonic&s;s 16SVPA82MAA conductive polymer aluminum solid capacitors to your circuit, you can ensure safe operation of the ICs and other components from unexpected loads. It can withstand a voltage of 16 VDC. It has 2 terminals. This product is 6.9 mm tall with a diameter of 8 mm. It has a tolerance of 20%. Its leakage current is 262@2Min μA. This conductive polymer aluminum solid capacitor has an operating temperature range of -55 °C to 105 °C.

安富利:
Cap Aluminum 82uF 16V 20% 8 X 6.9mm Cylindrical 0.03 Ohm 2760mA 2000 hr 105°C T/R

Verical:
Cap Aluminum Polymer 82uF 16VDC 20% 8 X 6.9mm SMD 0.03 Ohm 2760mA 2000h 105C T/R

Newark:
# PANASONIC ELECTRONIC COMPONENTS  16SVPA82MAA  CAP, ALU POLYMER, 82UF, 16V, RAD CAN
