1-640383-4

Conn Unshrouded Header HDR 14POS 3.96mm Solder ST Thru-Hole

针座 通孔 14 位置 0.156"（3.96mm）

得捷:
CONN HEADER VERT 14POS 3.96MM

艾睿:
This unshrouded 1-640383-4 header connector from TE Connectivity reduces the possibility of accidentally shorting pins when a board is being used. This HDR connector&s;s 14 contacts that are made out of copper alloy and plated with tin over nickel. It has a straight body orientation. This is a 1-row connector. It has a header type gender. It has a maximum voltage rating of 600 VAC. Its pitch is 3.96 mm. This device has a maximum current rating of 7 A/contact. It uses the solder termination method. 1-640383-4 is housed in white polyester. This connector has an operating temperature of -55 to 105 °C. This product is 55.47 mm long, 13.34 mm tall and 6.35 mm deep.

安富利:
Conn Unshrouded Header HDR 14 POS 3.96mm Solder ST Thru-Hole

Chip1Stop:
Conn Unshrouded Header HDR 14 POS 3.96mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 14 POS 3.96mm Solder ST Thru-Hole Package

Newark:
# AMP - TE CONNECTIVITY  1-640383-4  14P MTA156 HDR ASSY STR SQ SN New

MASTER:
MTA-156 HEADER ASSEMBLY, PLAIN, STRAIGHT, .045 SQUARE POST, TIN PLATED

Online Components:
14P MTA156 HDR ASSY STR SQ SN

Electro Sonic:
14P MTA156 HDR ASSY STR SQ SN
