1986722-2

TE CONNECTIVITY  1986722-2  接线端子块, 插入式, 2路, 30-14AWG

2 针位端子块 插头，母插口 0.150"（3.81mm） - 180° 自由悬挂

得捷:
TERM BLOCK PLUG 2POS STR 3.81MM

e络盟:
接线端子块, 插入式, 2路, 30-14AWG

艾睿:
Know that you will have strong connections between circuits when you use TE Connectivity&s;s 1986722-2 PCB terminal block. This F connector&s;s 2 contacts that are made out of copper alloy/steel. It has a maximum voltage rating of 300 VAC. This is a 1-row connector. It has a female type gender. Its pitch is 3.81 mm. It has a straight body orientation. This device has a maximum current rating of 11 A/contact. 1986722-2 is housed in polyamide. This quick disconnect terminal has an operating temperature of -40 to 110 °C. This product is 7.62 mm long, 11.65 mm tall and 20.75 mm deep. Its wire is 14-30 AWG.

Allied Electronics:
Buchanan; Conn; TermBlk; Plug; LeftHand; Spring; 2Pole; 3.81mm; 30-14AWG; 300V

Verical:
Conn Terminal Block F 2 POS 3.81mm ST Cable Mount 11A/Contact

Newark:
# TE CONNECTIVITY  1986722-2  Pluggable Terminal Block, 3.81 mm, 2 Positions, 30 AWG, 14 AWG, 2 mm², Push In

MASTER:
STRAIGHT SPRING TYPE PLUG CONNECTOR, SIDE STACKABLE LEFT, 02 - 25 POLES, PITCH 3

Online Components:
STR PLUG SPRING TYPE LH 2P, 3.81mm

Electro Sonic:
STR PLUG SPRING TYPE LH 2P, 3.81mm
