1881419

间距2.5mm 11位 公头 4A 160V 弹簧式 带测试孔 配线26-20AWG0.14-0.5mm²

**Features:**

* Polyamide Insulating Material

* Voltage: 125, Amps: 4, AWG: 28-20

* Spring-Cage Plug

* Suitable for Use in Miniature Modules with a High-Contact Density

* Plug-In Direction Parallel to the Conductor Axis

得捷:
TERM BLOCK PLUG 11POS STR 2.5MM

艾睿:
Conn Spring Cage SKT 11 POS 2.5mm Crimp ST Cable Mount 4A

Allied Electronics:
Conn; Term Blk; Plug; Spring Cage; 11; 2.5 mm; 26-20 AWG; Green; 4 A; 100 V; PA

Verical:
Plug component, Nominal current: 4 A, Nom. voltage: 100 V, Pitch: 2.5 mm, Number of positions: 11, Connection

MASTER:
PCB connector - nominal current: 4 A - rated voltage III/2: 160 V - nominal cross section: 0.5 mm² - number of positions: 11 - pitch: 2.5 mm - connection method: Push-in spring connection - color: green - contact surface: Tin

Online Components:
Conn Spring Cage SKT 11 POS 2.5mm Crimp ST Cable Mount 4A

Electro Sonic:
PCB connector - nominal current: 4 A - rated voltage III/2: 160 V - nominal cross section: 0.5 mm² - ...
