2N6073BG

ON SEMICONDUCTOR  2N6073BG  三端双向可控硅开关

TRIACS 4.0 A RMS, 200 − 600 V

Silicon Bidirectional Thyristors

Designed primarily for full-wave AC control applications, such as light dimmers, motor controls, heating controls and power supplies; or wherever full-wave silicon gate controlled solid-state devices are needed. Triac type thyristors switch from a blocking to a conducting state for either polarity of applied anode voltage with positive or negative gate triggering.

Features

•Sensitive Gate Triggering Uniquely Compatible for Direct Coupling to TTL, HTL, CMOS and Operational Amplifier Integrated Circuit Logic Functions

•Gate Triggering: 4 Mode − 2N6071A, B; 2N6073A, B; 2N6075A, B

•Blocking Voltages to 600 V

•All Diffused and Glass Passivated Junctions for Greater Parameter Uniformity and Stability

•Small, Rugged, Thermopad Construction for Low Thermal Resistance, High Heat Dissipation and Durability

•Device Marking: Device Type, e.g., 2N6071A, Date Code
