24LCS52T-I/MS

24LCS52系列 2kb I2C 双线 256x8位 2.2V 串行 电可擦除PROM 表面贴装-MSOP-8

Description:

The Technology Inc. 24AA52/24LCS52 24XXX52

.

is a 2 Kbit Electrically Erasable PROM capable of operation across a broad voltage range 1.8V to 5.5V. This device has a software write-protect feature for the lower half of the array, as well as an external pin that can be used to write-protect the entire array. The software write-protect feature is enabled by sending the device a special command. Once this feature has been enabled, it cannot be reversed. In addition to the software protect feature, there is a WP pin that can be used to write-protect the entire array, regardless of whether the software write-protect register has been written or not. This allows the system designer to protect none, half, or all of the array, depending on the application.

Features:

• Single Supply with Operation Down to 1.8V

• Low-Power CMOS Technology:

   - 1 mA active current, typical

   - 1 μA standby current, typical I-temp

• Organized as 1 Block of 256 Bytes 256 x 8

• Software Write Protection for Lower 128 Bytes

• Hardware Write Protection for Entire Array

• 2-Wire Serial Interface Bus, I2C™ Compatible

• Schmitt Trigger Inputs for Noise Suppression

• Output Slope Control to Eliminate Ground Bounce

• 100 kHz 24AA52 and 400 kHz 24LCS52 Compatibility

• Self-Timed Write Cycle including auto-erase

• Page Write Buffer for up to 16 Bytes

• ESD Protection > 4,000V

• 1,000,000 Erase/Write Cycles

• Data Retention > 200 Years

• 8-Lead PDIP, SOIC, TSSOP, MSOP, DFN and TDFN Packages

• Pb-Free Finishes Available

• Available for Extended Temperature Ranges:

   - Industrial I: -40°C to +85°C
