2092-1432

WAGO  2092-1432  接线端子块, PCB, 直角型, 12路, 5MM

The is a 12-pole 16A light grey Male Terminal Block Header with through-hole right-angled block orientation and angled solder pins. It has tin-plated electrolytic copper contact with glass fibre-reinforced polyphthalamide insulation. Assembly of female connectors without loss of poles, allowing different functions to be divided within one male header and coding pins inserted into the header interface prevent mismating, allowing subsequent coding in panel feed-through applications. The female connector is fully shrouded by the male header"s housing, providing vibration resistance up to 20g.

.

UL94V-0 Flammability rating

.

-60 to 100°C Operating temperature range
