0603 56pF ±5% 250V C0G
56 pF ±5% 250V 陶瓷器 C0G,NP0 0603(1608 公制)
得捷:
CAP CER 56PF 250V C0G/NP0 0603
立创商城:
56pF ±5% 250V
贸泽:
Multilayer Ceramic Capacitors MLCC - SMD/SMT 250volts 56pF 5%
艾睿:
Due to the use of different ceramic dielectric materials used in this 251R14S560JV4T multilayer ceramic capacitor from Johanson, you can choose the right capacitor based on capacitance values, voltage ratings, package sizes, and other parameters. It can withstand a voltage of 250 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This product is 1.57 mm long, 0.76 mm tall and 0.81 mm deep. It has a tolerance of 5%. Its capacitance value is 56pF.
Verical:
Cap Ceramic 56pF 250V C0G 5% Pad SMD 0603 125C Ultra Low ESR T/R
RfMW:
Hi-Q MLCC 0603,56pF,±5%
额定电压DC 250 V
电容 56 pF
容差 ±5 %
产品系列 High-Q
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 250 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.81 mm
高度 0.76 mm
封装公制 1608
封装 0603
厚度 0.76 mm
材质 C0G/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Unknown
包装方式 Tape & Reel TR
最小包装 4000
制造应用 RF,微波,高频
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
251R14S560JV4T Johanson Technology 约翰逊 | 当前型号 | 当前型号 |
0603N560J251LT 台湾华科 | 类似代替 | 251R14S560JV4T和0603N560J251LT的区别 |
NMC-H0603NPO560J250TRPF NIC | 类似代替 | 251R14S560JV4T和NMC-H0603NPO560J250TRPF的区别 |
ERB1885C2E560JDX5D 村田 | 功能相似 | 251R14S560JV4T和ERB1885C2E560JDX5D的区别 |
