1A 16A功率继电器，用于微波烤箱微波炉冰箱 1a 16A power relay for micro wave oven Microwave ovens Refrigerators
FEATURES
1\. Supports magnetron and heater loads.
Capable for switching magnetron and heater loads found in microwave ovens.
2\. Excellent heat resistance
Ambient temperature: up to 85°C 185°F Certified UL coil insulation class B and class F
3\. High insulation resistance Creepage distance and clearances between contact and coil:
Min. 8 mm .315 inch Surge withstand voltage: 10,000V
4\. Low operating power
Nominal operating power: 400mW/200mW High sensitive type
5\. A wide variety of types
Product line consists of 4 types with different shapes and pins
6\. Conforms to the various safety standards:
UL, CSA, TÜV and VDE approved
UL, CSA and VDE approved PCB type
TYPICAL APPLICATIONS
• Microwave ovens
• Refrigerators
• OA equipment
