Power/Signal Relay, POWER/SIGNAL RELAY, SPST, MOMENTARY, 0.017A COIL, 12VDC COIL, 200mW COIL, 5A CONTACT, 150VDC CONTACT, THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT
Power Relay 12VDC 5A SPST-NO17.5x10x12.5mm THT
贸泽:
General Purpose Relays 20-14 CRIMP PIN
艾睿:
Power Relay 12VDC 5A SPST-NO17.5x10x12.5mm THT
TME:
Relay: electromagnetic; SPST-NO; Ucoil:12VDC; 5A/250VAC; 5A/30VDC
Verical:
Electromechanical Relay 12VDC 720Ohm 5A SPST-NO 17.5x10x12.5mm THT Power Relay
儒卓力:
**POWER RELAY 12V 5A 1NO THT **
MASTER:
Power Relay 12VDC 5A SPST-NO17.5x10x12.5mm THT
Online Components:
Power Relay 12VDC 5A SPST-NO17.5x10x12.5mm THT
Electro Sonic:
Power Relay 12VDC 5A SPST-NO17.5x10x12.5mm THT
额定电压DC 150 V
额定电压AC 250 V
触点类型 SPST-NO
功耗 200 mW
触点额定电流 5 A
线圈电压 12 V
线圈电流 16.67 mA
线圈电阻 720 Ω
线圈电压DC 12 V
额定功率Max 150W, 1.25KVA
开关电流Max 5 A
工作温度Max 70 ℃
工作温度Min -40 ℃
安装方式 Through Hole
引脚数 4
封装 DIP
长度 17.5 mm
宽度 12.5 mm
高度 12.5 mm
封装 DIP
触点材质 Silver
工作温度 -40℃ ~ 70℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
ECCN代码 EAR99
HTS代码 8536490050
