混合信号微控制器 MIXED SIGNAL MICROCONTROLLER
MSP430 MSP430x4xx Microcontroller IC 16-Bit 8MHz 24KB 24K x 8 + 256B FLASH 100-LQFP 14x14
得捷:
IC MCU 16BIT 24KB FLASH 100LQFP
立创商城:
MSP430 8MHz 闪存:24K@x8bit RAM:1KB
德州仪器TI:
8 MHz MCU with 24KB Flash, 1KB SRAM, 12-bit ADC, comparator, SPI/UART, 160 seg LCD
贸泽:
16位微控制器 - MCU 24kB Flash 1MB RAM 12bADC/USART 160sLCD
艾睿:
Need a strong device that can control other devices in your circuit design? Look no further. This MSP430F436IPZR microcontroller manufactured by Texas Instruments will meet and excel your needs. This microcontroller has a minimum operating temperature of -40 °C and a maximum of 85 °C. It has a maximum clock speed of 8 MHz. Its ADC resolution is 12. This is a 16 bit processor. This device is based on the MSP430 core architecture. This device has a typical operating supply voltage of 2.5|3.3 V. Its minimum operating supply voltage of 1.8 V, while its maximum is 3.6 V. Its flash program memory is 24KB.
安富利:
MCU 16-bit MSP430 RISC 24KB Flash 2.5V/3.3V 100-Pin LQFP T/R
TME:
MSP430 microcontroller; SRAM:1024B; Flash:24kB; 8MHz; LQFP100
Win Source:
MSP430 MSP430x4xx Microcontroller IC 16-Bit 8MHz 24KB 24K x 8 + 256B FLASH 100-LQFP 14x14
频率 8.00 MHz
电源电压DC 1.80V min
时钟频率 8.00 MHz
RAM大小 1K x 8
FLASH内存容量 24576 B
I/O引脚数 48
内核架构 MSP430
UART数量 1
模数转换数ADC 1
FRAM内存容量 0 B
工作温度Max 85 ℃
工作温度Min -40 ℃
安装方式 Surface Mount
引脚数 100
封装 LQFP-100
长度 14 mm
宽度 14 mm
高度 1.4 mm
封装 LQFP-100
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MSP430F436IPZR TI 德州仪器 | 当前型号 | 当前型号 |
MSP430F437IPZR 德州仪器 | 类似代替 | MSP430F436IPZR和MSP430F437IPZR的区别 |
MSP430F449IPZR 德州仪器 | 类似代替 | MSP430F436IPZR和MSP430F449IPZR的区别 |
MSP430F436IPZ 德州仪器 | 类似代替 | MSP430F436IPZR和MSP430F436IPZ的区别 |
