310-91-164-41-001000

64Position 2.54mm Pitch Through Hole Sip Socket

Interconnect Socket

Standard Solder Tail Socket

Accepts .015"- .025" 0,38 - 0,635 mm dia leads

Single Row Through Hole

得捷:
CONN RCPT 64POS 0.1 GOLD PCB

贸泽:
IC & Component Sockets 64P SINGLE IN LINE SKT STD SOLDER TAIL

艾睿:
This socket strip 310-91-164-41-001000 header connector from Mill-Max Mfg. Corp. reduces the possibility of accidentally shorting pins when a board is being used. This SKT connector&s;s 64 contacts that are made out of beryllium copper alloy and plated with gold over nickel. It has a straight body orientation. It has a maximum voltage rating of 150 VDC|100VAC. It has a socket type gender. This is a 1-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 3 A. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. 310-91-164-41-001000 is housed in black polychlorinated terphenyl. This product is 162.56 mm long, 4.19 mm tall and 2.54 mm deep.

Allied Electronics:
SOCKET SOLDERTAIL SIP 64POS

Verical:
Conn Socket Strip SKT 64 POS 2.54mm Solder ST Thru-Hole
