4-1393789-9

P2 系列 2 A 双刀双掷 5 VDC 表面贴装 通信/信号 PCB 继电器

* Standard telecom relay ringing and test access * Slim line 15x7.5mm .590x.295” * Max. switching current 5A * 2 form C bifurcated contacts 2 changeover contacts, 2 CO * Immersion cleanable * High sensitivity for low power consumption 140mW/ 70mW * Single coil version with surge voltage resistance between contact and coil: 2.5kV 2/10μs meets the Telcordia Requirement GR-1089, 1.5kV 10/160μs meets FCC Part 68

立创商城:
4-1393789-9

艾睿:
Signal Relay 5VDC 2A DPDT 14.6mm 7.4mm 9.9mm SMD Automotive Medical

安富利:
Electromechanical Relay DPDT 2A 5VDC 178Ohm Surface Mount

Chip1Stop:
Electromechanical Relay 5VDC 178Ohm 2A DPDT 14.6mm 7.4mm 9.9mm SMD Signal Relay Automotive Medical

TME:
Relay: electromagnetic; DPDT; Ucoil:5VDC; 0.5A/125VAC; 2A/30VDC

Verical:
Electromechanical Relay 5VDC 178Ohm 2A DPDT 14.6mm 7.4mm 9.9mm SMD Signal Relay Automotive Medical

MASTER:
V23079G2001B301

Powell:
3G COM Relay P2

Electro Sonic:
V23079G2001B301
