Res Thick Film NET 1KΩ 2% 1.25W 100ppm/℃ LADDER Molded 10Pin SIP Pin Thru-Hole
1k, 2k Ohm ±2% 125mW Power Per Element R2R Ladder Resistor Network/Array ±100ppm/°C 10-SIP
得捷:
RES NTWRK 16 RES MULT OHM 10SIP
立创商城:
2kΩ 1kΩ ±2%
艾睿:
Pack multiple resistors into a single chip with this 4310R-R2R-102LF resistor array from Bourns. Its temperature coefficient is ±100 ppm/°C. This product&s;s 16 resistors have a value of 1K Ohm. This dependable part has a power rating of 1.25 W and a power rating per resistor of 0.125 1/8 W. It has 10 terminals. It has a tolerance of 2%. This device is made with thick film technology. The 4310R-R2R-102LF part has a pin termination style. This product&s;s terminal pitch is 2.54 mm. This product is 24.99 mm long, 4.95 mm tall and 2.16 mm deep. This part has an operating temperature of -55 to 125 °C.
安富利:
Res Thick Film NET 1K Ohm 2% 1.25W ±100ppm/°C LADDER Molded 10-Pin SIP Pin Thru-Hole
Chip1Stop:
Res Thick Film NET 1K Ohm 2% 1.25W 100ppm/ C LADDER Molded 10-Pin SIP Pin Thru-Hole
Verical:
Res Thick Film NET 1K Ohm 2% 1.25W ±100ppm/C LADDER Molded 10-Pin SIP Pin Thru-Hole
Electro Sonic:
Res Thick Film NET 1K Ohm 2% 1.25W ±100ppm/°C LADDER Molded 10-Pin SIP Pin Thru-Hole
