2.54mm P数:20
20 位置 母头 非指定 - 双边 镀金 0.100"(2.54mm) 黑色
立创商城:
2.54mm P数:20
得捷:
CONN EDGE DUAL FMALE 20POS 0.100
艾睿:
TE Connectivity&s;s 5-650297-1 smart card connector is a great component to use if you are looking to reduce component cost. This SKT connector&s;s 20 contacts that are made out of phosphor bronze and plated with gold. It has a straight body orientation. Its pitch is 2.54 mm. It has a socket type gender. 5-650297-1 is housed in black polyester. It uses the press fit termination method.
安富利:
Conn Card Edge SKT 20 POS 2.54mm Press Fit ST Thru-Hole
MASTER:
CONNECTOR, AMP PACE .100x.200
Powell:
.100, .125, .150, .156 Centerline Press-Fit Connectors AMP PACE and AMP ECONOMATE
Online Components:
AMP PACE CONN 10POS 100X200C/L
触点数 20
极性 Female
触点电镀 Gold, Tin
排数 2
方向 Vertical
易燃性等级 UL 94 V-0
针脚数 20
额定电流Max 3A/触头
工作温度Max 85 ℃
工作温度Min -65 ℃
安装方式 Through Hole
封装 -
高度 16.38 mm
封装 -
外壳颜色 Black
颜色 Black
触点材质 Phosphor Bronze
工作温度 -55℃ ~ 85℃
外壳材质 Polyester
产品生命周期 Active
包装方式 Tray
制造应用 Signal
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536694040
