5223008-4

Conn Backplane RCP 120POS 2mm Press Fit RA Thru-Hole

120 插座，母型插口 板边缘，通孔，直角 天然 Futurebus

得捷:
CONN RCPT FUTUREBUS 120P EDGE MT

艾睿:
When you have numerous wires connected in parallel, then use this 5223008-4 backplane connector from TE Connectivity to make sure all the data flows through. This RCP connector&s;s 120 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a right angle body orientation. This is a 5-row connector. It has a maximum voltage rating of 30 VAC. Its pitch is 2 mm. It has a receptacle type gender. This device has a maximum current rating of 3 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 47.88 mm long, 13.8 mm tall and 22.45 mm deep. It uses the press fit termination method. This backplane connector has an operating temperature of -55 to 125 °C. 5223008-4 is housed in natural liquid crystal polymer.

安富利:
Conn Backplane RCP 120 POS 2mm Press Fit RA Thru-Hole

Chip1Stop:
Conn Backplane RCP 120 POS 2mm Press Fit RA Thru-Hole Tube

Verical:
Conn Backplane RCP 120 POS 2mm Press Fit RA Thru-Hole Tube

Newark:
# AMP - TE CONNECTIVITY  5223008-4  FB-5R,ASY,120,SIG,REC,EN,3.55 New

MASTER:
ASSEMBLY, RECEPTACLE, SIGNAL, RIGHT ANGLE, Z-PACK 2mm FB, 5 ROW, PRESS FIT LEAD

Powell:
2mm Centerline Futurebus+ Connectors

Online Components:
FB-5R,ASY,120,SIG,REC,EN,3.55

Electro Sonic:
FB-5R,ASY,120,SIG,REC,EN,3.55
