Diode TVS Single Uni-Dir 14V 5kW 2Pin SMC T/R
23.2V 夹子 216A Ipp TVS - 表面贴装型 DO-214AB（SMCJ）
得捷:
TVS DIODE 14VWM 23.2VC DO214AB
立创商城:
Vrwm:14V 5kW
贸泽:
ESD Suppressors / TVS Diodes 14V 5KW 5% UNI DO-214AB
艾睿:
Littelfuse&s;s 5.0SMDJ14A-T7 TVS diode is designed to protect electronic components and circuits from electrical overstress from overvoltage and electrostatic discharge. Its test current is 10 mA. Its maximum leakage current is 200 μA. Its peak pulse power dissipation is 5000 W. This device&s;s maximum clamping voltage is 23.2 V and minimum breakdown voltage is 15.6 V. This TVS diode has an operating temperature range of -55 °C to 150 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery.
Verical:
TVS Diode Single Uni-Dir 14V 5KW 2-Pin SMC T/R
