5.0SMDJ130A

5.0SMDJ系列 209V 5kW 表面贴装 单向 瞬态电压抑制二极管 DO-214AB

Description

The 5.0SMDJ series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

Applications

TVS devices are ideal for the protection of I/O Interfaces, VCC bus and other vulnerable circuits used in Telecom,

Computer, Industrial and Consumer electronic applications.

得捷:
TVS DIODE 130VWM 209VC DO214AB

立创商城:
单向 Vrwm:130V 5kW

艾睿:
This 5.0SMDJ130A TVS diode developed by Littelfuse can help protect your expensive equipment and electronics. This device&s;s maximum clamping voltage is 209 V and minimum breakdown voltage is 144 V. Its peak pulse power dissipation is 5000 W. Its maximum leakage current is 5 μA. Its test current is 1 mA. This TVS diode has an operating temperature range of -55 °C to 150 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery.

Chip1Stop:
Diode TVS Single Uni-Dir 130V 5KW 2-Pin DO-214AB T/R

Win Source:
TVS DIODE 130VWM 209VC SMD
