5LS1

HONEYWELL  5LS1  预接线限位开关

Enclosed Switches Series LS Top Roller Plunger

The Compact LS has a long record of successful performance in industrial applications. The LS fits in many places too small for any other fully adjustable limit switch.

** Features**

* Wide Choice of Operating Heads and Actuators

* Captive Screws

** Specifications**

* Field Adjustable Rotary Motion Actuators Through 360°

* Sealing: NEMA 1, 3, 4, 6, 13

e络盟:
HONEYWELL  5LS1  预接线限位开关

艾睿:
Look no further than the compact 5LS1 limit switch from Honeywell, a device that operates via the switch&s;s motion or in the presence of another object. 5LS1 is housed in zinc die cast. It has a SPDT configuration. This device has a maximum current rating of 0.8 A @ 115VDC. This limit switch has an operating temperature range of -29 °C to 71 °C. The 5LS1 limit switch has a conduit termination style. This product is 39.88 mm long, 109.09 mm tall and 40.64 mm deep. The maximum AC voltage rating is 240 VAC and the maximum DC voltage rating is 550 VDC.

Allied Electronics:
Switch, COMPACT, Limit, Actuator-Roller LEVER, 2 CIRCUIT DOUBLE BREAK

Chip1Stop:
Switch Limit N.O./N.C. SPDT Top Roller Plunger Conduit 0.8A 240VAC 550VDC 3/4HP 31.14N Linear Screw Mount

Verical:
Switch Limit N.O./N.C. SPDT Top Roller Plunger Screw Mount 0.8A 240VAC 550VDC 3/4HP 31.14N Linear Conduit Automotive

Newark:
# HONEYWELL  5LS1  Limit Switch, Top Roller Plunger, SPDT-1NO, SPDT-NC, 10 A, 480 V, 7 lbf

MASTER:
MICRO SWITCH™ Medium-Duty Limit Switches: LS Series Enclosed Switch, Top Roller Plunger Actuator, 1NC 1NO Single Pole Double Throw SPDT Snap Action, Double Break, 0.5 in - 14NPT Conduit, Compact/Non Plug-in

Electro Sonic:
MICRO SWITCH™ Medium-Duty Limit Switches: LS Series Enclosed Switch, Top Roller Plunger Actuator, 1NC 1NO Single Pole Double Throw SPDT ...
