5962-8404501VDA

四路2输入正或门 QUADRUPLE 2-INPUT POSITIVE-OR GATES

description

The ’HC32 devices contain four independent 2-input OR gates.

Wide Operating Voltage Range of 2 V to 6 V

Outputs Can Drive Up To 10 LSTTL Loads

Low Power Consumption, 20-µA Max ICC

Typical tpd = 8 ns

±4-mA Output Drive at 5 V

Low Input Current of 1 µA Max

艾睿:
OR Gate 4-Element 2-IN CMOS 14-Pin CFPAK Tube

安富利:
OR Gate 4-Element 2-IN CMOS 14-Pin CFPAK Tube

德州仪器TI:
Space 4-ch, 2-input, 2-V to 6-V OR gates
