74AHCT1G125DBVRE4

具有三态输出单总线缓冲器门 SINGLE BUS BUFFER GATE WITH 3-STATE OUTPUT

Description

The SN74AHCT1G125 device is a single bus buffer gate/line driver with 3-state output. The output is disabled when the output-enable OE input is high. When OE is low, data is passed from the A input to the Y output.

Features

• Operating Range of 4.5 V to 5.5 V

• Max tpd of 6 ns at 5 V

• Low Power Consumption, 10-µA Max ICC

• ±8-mA Output Drive at 5 V

• Inputs are TTL-Voltage Compatible

• Latch-Up Performance Exceeds 250 mA Per JESD 17

Applications

• Wireless Infrastructure

• Servers

• Power Infrastructure

• PCs/Notebooks

• Programmable Logic Controllers

• Tests and Measurements
