单总线缓冲器（三态） SINGLE BUS BUFFER 3-STATE
Leading the input to the transmission line this buffer and line driver by STMicroelectronics will amplify digital and analog signals. With a 3-state output, this is power management at its best. This line driver has an operating temperature range of -55 °C to 125 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V. It has 1 channels per chip.
电源电压DC 5.00 V, 5.50 V max
输出接口数 1
通道数 1
位数 1
输入数 1
工作温度Max 125 ℃
工作温度Min -55 ℃
电源电压 4.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
长度 3 mm
宽度 1.75 mm
高度 1.3 mm
封装 SOT-23-5
工作温度 -55℃ ~ 125℃ TA
产品生命周期 Not Recommended for New Designs
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
