NXP 74ABT245D 收发器, 非反相, 3态, 8门, 1输入, 4.5V至5.5V, SOIC-20
The is an octal bidirectional Bus Interface Transceiver featuring non-inverting 3-state bus compatible outputs in both send and receive directions. The control function implementation minimizes external timing requirements. The device features an output enable OE input for easy cascading and a direction DIR input for direction control. The 74ABT245 high-performance BiCMOS device combines low static and dynamic power dissipation with high speed and high output drive.
电源电压DC 5.00 V
电路数 8
通道数 8
针脚数 20
位数 8
静态电流 50.0 µA
逻辑门个数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 20
封装 SOIC
长度 13 mm
宽度 7.6 mm
高度 2.45 mm
封装 SOIC
产品生命周期 Unknown
包装方式 Tube
制造应用 Industrial, Signal Processing
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
