单芯片、多个RS-232驱动器和接收器、高数据传输率
■ DESCRIPTION
The complies with the requirements of the TIA/EIA232-F and ITU formerly CCITT v.28 standards. These standards are for data interchange between a host computer and peripheral at signaling rates up to 20kbit/s. The switching speeds of the UTC 75185 are fast enough to support rates up to 120kbite/s with lower capacitive loads shorter cables. Interoperability at the higher signaling rates cannot be assured unless the designer has design control of the cable and the interface circuits at both ends. For interoperability at signaling rates to 120kbit/s, use of ITA/EIA-423-B ITU v.10 and TIA/EIA-422-B ITU v.11 standards are recommended.
■ FEATURES
* Single Chip with Easy Interface between UART and Serial-Port connector of PC.
* Three Drivers and five Receivers Meet or Exceed the Requirements of TIA/EIA-232-F and ITU v.28 Standards.
* Designed to Support Data Rates up to 120 kbps
