NLC453232T-220K-PF

TDK  NLC453232T-220K-PF  电源线电感, 22uH, 1812

固定器

立创商城:
22uH ±10% 900mΩ

得捷:
FIXED IND 22UH 370MA 900MOHM SMD

贸泽:
Fixed Inductors 22uH 10%

e络盟:
电源线电感, 22uH, 1812

艾睿:
Save valuable space on a PCB with this power NLC453232T-220K-PF surface mount inductor from TDK. This SMD inductor has an operating temperature range of -40 °C to 105 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This product is 4.8 mm long, 3.4 mm tall and 3.4 mm deep. It has an inductance of 22u H. This SMD inductor has a maximum DC current of 370m A with a maximum resistance of 900m Ohm. It has a tolerance of 10%. This device utilizes wirewound technology. Its test frequency is 2.52M Hz, while its minimum self-resonant frequency is 18M Hz.

安富利:
Ind Power Wirewound 22uH 10% 2.52MHz 10Q-Factor 370mA 1812 T/R

Chip1Stop:
Ind Power Unshielded Wirewound 22uH 10% 2.52MHz 10Q-Factor 370mA 4.5 x 3.2 mm T/R

Verical:
Inductor General Purpose Chip Molded/Unshielded Wirewound 22uH 10% 2.52MHz 10Q-Factor Ferrite 0.37A 0.9Ohm DCR 1812 T/R

Newark:
# TDK  NLC453232T-220K-PF  Surface Mount High Frequency Inductor, NLC Series, 22 µH, 370 mA, 1812 [4532 Metric], Wirewound

儒卓力:
**NLC453232T 22uH 370mA 10% WWT **

MASTER:
Inductor Power Unshielded Wirewound 22uH 10% 2.52MHz 10Q-Factor Ferrite 370mA 900mOhm DCR 1812 T/R

Electro Sonic:
Inductor Power Unshielded Wirewound 22uH 10% 2.52MHz 10Q-Factor Ferrite 370mA 900mOhm DCR 1812 T/R

Win Source:
22μH Unshielded Wirewound Inductor 370mA 900 mOhm Max 1812 4532 Metric
