NTE1205MC-R

NTE1205MC-R 编带

The NTE series of miniature surface mounted DC/DC Converters employ leadframe technol ogy and transfer moulding techniques to bring all of the benefits of IC style packaging to hybrid circuitry. The co-planarity of the pin positions is based upon IEC 191-6:1990. The devices are suitable for all applications where high volume

production is envisaged.

FEATURES

„RoHS compliant

„Lead frame technology

„Single isolated output

„1kVDC Isolation

„Efficiency up to 78%

„Power density 1.8W/cm3

„Wide temperature performance at full 1 Watt load, –40°C to 85°C

„UL 94V-0 Package material

„Footprint over pins 1.37cm2

„3.3V, 5V & 12V Input

„3.3V, 5V, 9V, 12V & 15V output

„No heatsink required

„Internal SMD construction

„Toroidal magnetics

„MTTF up to 6.8 million hours

„Custom solutions available

„Multi-layer ceramic capacitors
