5-104666-1

板对板与夹层连接器 20 SYSTEM 50 HDR DRST SHRD SN

Reduce the possibility of accidentally shorting pins when using a printed circuit board with this shrouded header connector from . This HDR connector"s 20 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. It has a straight body orientation. Its pitch is 1.27 mm. It has a maximum voltage rating of 30 VAC. This is a 2-row connector. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. 5-104666-1 is housed in black thermoplastic. It uses the solder termination method. This product is 18.9 mm long, 9.91 mm tall and 8.74 mm deep. This connector has an operating temperature of -65 to 105 °C.
