BK500概述

Uninterruptible Power Supply 500VA 300W 120VAC Input 120VAC Output USB Port Surface Mount

Best Value Battery Backup and Protection for Business Computers.
.
*Features:**

* File-Saving, Auto-Shutdown Software USB

* Power Range from 350-500 VA

* Six Power Outlets Three UPS and Three Surge

* Input/Output Voltage = 120 V

* RJ-11 Modem/Fax/DSL Protection

* LED Indicators Provide Proactive Notification of Changing Power and UPS Conditions

* Up to 55 Minutes of Runtime


艾睿:
This BK500 uninterruptible power supply made by American Power Conversion will continue to supply power when power outages occur. It has a voltage of 120. This part has a minimum operating temperature of 0 °C and a maximum of 40 °C.


Allied Electronics:
UPS; Network; 120V Out; 300/500 W/VA; 120V Sup; 3.4min. Bkup; 3 NEMA 5-15R Out; Beige


Newark:
The BK500 is a 6-outlet beige Uninterruptible Power Supply offers guaranteed power protection. The Back-UPS® - tower style supply battery backup during outages and unsafe voltage fluctuations, as well as provide protection from damaging surges and spikes. The dataline surge protection provides protection of connected equipment from power surges on the data lines. The surge only outlets protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage. The transformer-block spaced outlets protect equipment with input transformer blocks without blocking access to other receptacles. The audible alarm provides notification of changing utility power and UPS power conditions.


BK500中文资料参数规格
技术参数

额定功率 300 W , 500 VA

输入电压DC 98.0V ~ 140V

输出电压 120 V

输出功率 500 VA

工作温度Max 40 ℃

工作温度Min 0 ℃

电源电压 120 VAC

输入电压 120 VAC

封装参数

封装 120

外形尺寸

长度 284 mm

宽度 3.6 in

高度 165 mm

封装 120

电源线长度 1.83 m

物理参数

颜色 Beige

重量 6.27 kg

其他

产品生命周期 Active

包装方式 Bulk

制造应用 Power Management

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买BK500
型号: BK500
制造商: American Power Conversion 美国电力转换公司
描述:Uninterruptible Power Supply 500VA 300W 120VAC Input 120VAC Output USB Port Surface Mount
