Cap Aluminum 3300uF 400V 20% 64.3 X 105.7mm Clamp Mount Metal Can 0.034Ω 11000mA 12000 hr 85℃ Bulk
**Features:
**
* Tolerance: 20%**
**
* High Reliability and High Ripple Current Capability**
**
* All-Welded Construction Ensures Reliable Electrical Contact**
Applications:
**
* Uninterruptible Power Supplies**
**
* Frequency Converters**
Construction:
**
* Charge-Discharge Proof, Polar**
**
* Aluminum Case with Insulating Sleeve**
**
* Poles with Screw Terminations**
**
* Mounting with Ring Clips, Clamps
额定电压DC 400 V
电容 3300 μF
等效串联电阻ESR 23mΩ @100Hz
容差 ±20 %
测试频率 100 Hz
纹波电流 11A @100Hz
工作温度Min -40 ℃
额定电压 400 V
安装方式 Screw
引脚数 2
封装 Radial, CAN
高度 105.7 mm
直径 64.3 mm
封装 Radial, CAN
介质材料 Aluminum Electrolytic
工作温度 -40℃ ~ 85℃
包装方式 Bulk
寿命（小时） 12000h @85℃
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
