ISO7840FDW

高隔离额定值、四通道、4/0、增强型数字隔离器 16-SOIC -55 to 125

The is a quad-channel Digital Isolator with a 8000VPK isolation voltage. This device has reinforced isolation certifications according to VDE, CSA, CQC and TUV. The isolator provides high electromagnetic immunity and low emissions at low-power consumption, while isolating CMOS or LVCMOS digital I/Os. Each isolation channel has a logic input and output buffer separated by a silicon-dioxide SiO2 insulation barrier. This device comes with enable pins that can be used to put the respective outputs in high impedance for multi-master driving applications and to reduce power consumption. The ISO7840 device has four forward and zero reverse-direction channels. Used in conjunction with isolated power supplies, this device helps prevent noise currents on a data bus or other circuits from entering the local ground and interfering with or damaging sensitive circuitry.

.

±100kV/µs Industry leading CM Min

.

Robust electromagnetic compatibility EMC

.

System-level ESD, EFT and surge immunity

.

Low emissions

.

>40 Years isolation barrier life

.

Green product and no Sb/Br

Device has limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
