FTSH-105-01-F-DV和FTSH-105-01-L-DV

对比图

型号 FTSH-105-01-F-DV FTSH-105-01-L-DV FTSH-105-01-F-DV-TR

描述 Surface Mount Micro Headers - FTSH SeriesFTSH series SMT micro headers with a 1.27 mm pitch and gold plated contacts. This range of FTSH Series 1.27 mm pitch SMT micro terminal strips can be mated with appropriate socket strips or IDC cable assemblies.Current rating 1.75 A at 80 °C Operating temperature -55 to 125 °C### 注**FTSH Series SMT Terminal Strips mate with:** FFSD Series IDC cable assemblies, see stock number 159-880 typical. CLP Series micro socket strips, see stock number 481-4695 typical. FLE Series socket strips, see stock number 766-8959 typical.SAMTEC  FTSH-105-01-L-DV  板至板连接, FTSH系列, 10 触点, 针座, 1.27 mm, 表面安装　, 2 排Conn Unshrouded Header HDR 10POS 1.27mm Solder ST SMD T/R

数据手册 ---

制造商 Samtec (申泰电子) Samtec (申泰电子) Samtec (申泰电子)

分类 板对板连接器板对板连接器板对板连接器

安装方式 Surface Mount Surface Mount Surface Mount

引脚间距 - 1.27 mm -

触点数 10 10 10

极性 Male Male Male

触点电镀 - Gold -

额定电流 3.3A/触头 1.75 A -

排数 2 2 2

针脚数 10 10 -

额定电流(Max) 3.4A/触头 3.4A/触头 3.3A/触头

工作温度(Max) - 125 ℃ -

工作温度(Min) - -55 ℃ -

长度 - 6.35 mm -

宽度 - 3.43 mm -

高度 5.97 mm 5.97 mm 5.97 mm

引脚间距 - 1.27 mm -

外壳颜色 Black Black Black

颜色 - Black -

触点材质 Phosphor Bronze Phosphor Bronze Phosphor Bronze

工作温度 -55℃ ~ 125℃ -55℃ ~ 125℃ -55℃ ~ 125℃

外壳材质 - Plastic -

产品生命周期 Active Active Active

包装方式 Tube Bulk Tape & Reel (TR)

RoHS标准 RoHS Compliant RoHS Compliant RoHS Compliant

含铅标准 Lead Free Lead Free Lead Free

REACH SVHC标准 - No SVHC -

REACH SVHC版本 - 2015/06/15 -
