ATMEGA8L-8AUR

ATMEL  ATMEGA8L-8AUR  微控制器, 8位, 低功率高性能, ATmega, 8 MHz, 8 KB, 1 KB, 32 引脚, TQFP

The is a low-power 8-bit CMOS AVR RISC-based Microcontroller. By executing powerful instructions in a single clock cycle, the ATmega8 achieves throughputs approaching 1MIPS per MHz, allowing the system designer to optimize power consumption versus processing speed. The ATmega8 provides 8kB of in-system programmable flash with read-while-write capabilities, 512byte of EEPROM, 1kB of SRAM, 23 general purpose I/O lines, 32 general purpose working registers, three flexible timers/counters with compare modes, internal and external interrupts, a serial programmable USART, a byte oriented Twowire Serial Interface, a 6-channel ADC with 10-bit accuracy, a programmable Watchdog Timer with Internal Oscillator, an SPI serial port and five software selectable power saving modes.

.

Advanced RISC architecture

.

Power-on reset and programmable brown-out detection

.

Internal calibrated RC oscillator

.

External and internal interrupt sources

.

Five sleep modes - Idle, ADC noise reduction, power-save, power-down and standby

.

130 Powerful instructions-most single clock cycle execution

.

32 x 8 General purpose working registers

.

Fully static operation

.

Up to 16MIPS throughput at 16MHz

.

On-chip 2-cycle multiplier

.

Programmable watchdog timer with separate on-chip oscillator

.

On-chip analog comparator

.

Two 8-bit timers/counters with separate prescalers and one compare modes

.

One 16-bit timer/counter with separate prescaler, compare mode and capture mode

.

Real-time counter with separate oscillator

.

Three PWM channels

.

Programmable serial USART

.

Master/Slave SPI serial interface

.

Byte-oriented two-wire serial interface
