LGW2E681MELB30

680uF ±20% 250V 2550mA Φ30mm

680µF 250V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 3000 Hrs @ 105°C

得捷:
CAP ALUM 680UF 20% 250V SNAP

立创商城:
680uF ±20% 250V

艾睿:
Who knew generating high heat for a given current level would be this easy? Pick up this unique electrolytic LGW2E681MELB30 aluminum capacitor from Nichicon for its relatively high ESR! It can withstand a voltage of 250 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. The LGW2E681MELB30 aluminum electrolytic capacitor has a snap-in termination style. This product is 30 mm tall with a diameter of 30 mm. This part has a lead diameter of 0.8 mm and a pitch of 10 mm. It has a tolerance of 20%. Its leakage current is 1230@5Min μA. Its capacitance value is 680uF.

TME:
Capacitor: electrolytic; THT; 680uF; 250VDC; Ø30x30mm; ±20%; 3000h

Verical:
Cap Aluminum Lytic 680uF 250V 20% 30 X 30mm Snap-In 10mm 2550mA 3000h 105C Bulk
