SDR0403-150ML

BOURNS  SDR0403-150ML  表面贴装功率电感器, SDR0403系列, 15 µH, ± 20%, 非屏蔽, 0.24 ohm, 920 mA

SDR0403 系列线绕扼流圈

提供 E12 系列

薄型，仅 3.2mm

低值

符合 RoHs

应用于直流/直流转换器的输入/输出以及电源

得捷:
FIXED IND 15UH 920MA 240MOHM SMD

欧时:
### SDR0403 系列线绕扼流圈提供 E12 系列 薄型，仅 3.2mm 低电感值 符合 RoHs 应用于直流/直流转换器的输入/输出以及电源 ### Bourns 非标准表面安装电感器（扼流圈）

立创商城:
15uH ±20% 920mA 240mΩ

e络盟:
功率电感SMD, 15 µH, 920 mA, 非屏蔽, 1.4 A, SDR0403系列, 4.5mm x 4mm x 3.2mm

艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this power SDR0403-150ML surface mount inductor from Bourns to save valuable space. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This SMD inductor has a maximum DC current of 920m A with a maximum resistance of 240m Ohm. This product is 4.8 mm long, 3.5 mm tall and 4.3 mm deep. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 28M Hz. It has an inductance of 15u H. It has a tolerance of 20%. This device utilizes wirewound technology.

Allied Electronics:
Inductor; Power; Non-Shielded; Wirewound; 15uH; 20%; 0.92A

安富利:
Ind Power Wirewound 15uH 20% 1KHz 28Q-Factor Ferrite 920mA T/R

Chip1Stop:
Ind Power Wirewound 15uH 20% 1KHz 28Q-Factor Ferrite 920mA T/R

Verical:
Inductor Power Unshielded Wirewound 15uH 20% 1KHz 28Q-Factor Ferrite 0.92A 0.24Ohm DCR T/R

Newark:
# BOURNS  SDR0403-150ML  Surface Mount Power Inductor, SDR0403 Series, 15 µH, 920 mA, 1.4 A, Unshielded, 0.24 ohm

MASTER:
Inductor Power Wirewound 15uH 20% 1KHz 28Q-Factor Ferrite 920mA 240mOhm DCR T/R

Online Components:
Inductor Power Wirewound 15uH 20% 1KHz 28Q-Factor Ferrite 920mA 240mOhm DCR T/R

Electro Sonic:
Inductor Power Wirewound 15uH 20% 1KHz 28Q-Factor Ferrite 920mA 240mOhm DCR T/R
